JUKI | JM10/20 Hybrid SMT and Through Hole Placement machine

תיאור המוצר

Achieve higher quality and labor savings by automating manual insertion.

The JM10/JM20 automates the manual insertion process and is the advanced model for larger/heavier components and larger boards.

  • Placement or Insertion of Surface Mount & Through-Hole Components
  • Widest Component Range in the Electronics Industry
  • Accommodates Multiple Types of Feeders

Features:

The TM 10/20 is a Hybrid SMT and Through Hole Placement machine; Compact Footprint. An advanced model for larger and heavier components and larger boards.

  • 6 specialty nozzles per gantry allow for a wide variety of applications.
  • Through Hole Placement with lead tip centering
  • Lead Orientation Detection – The laser sensor is ideal for lead tip detections leading to an improved insertion process
  • Radial Feeders – MRF-S/MRF-L, or snap-in MRF-LF
  • Bowl Feeders – MBF (Fixed), MBF-C (Trolley) or MBF-L (for large components)
  • High accuracy low noise ball screw drive
  • High accuracy laser align component centering – Laser sensor integrated into placement head

מידע נוסף

Manufacturer

ספסיפיקציות

BOARD SIZE

JM-10 Board Size:
Insertion & Surface Mounting
Min.50×50~Max.410×250mm

JM-20 Board Size:
• L Size:
410x360mm(single clamp)
to 800x360mm (double clamp)
• XL Size:
410x560mm (single clamp)
to 800x560mm (double clamp)

COMPONENT SPECS

JM-10/20 Component Height:
• 28mm (component body 25mm +
lead length 3mm)

JM-10/20 Component Size:
• Laser:
0603 (0201)~□33.5mm

FEEDER INPUTS

JM-10 Feeder Inputs:
• Bowl Feeder: 12 types max
• Radial Feeder: 20 types max
• Axial Feeder: 16 types max

JM-20 Feeder Inputs:
• Bowl Feeder: 16 types max
• Radial Feeder: 26 types max
• Axial Feeder: 22 types max

PLACEMENT SPECS

JM-10 Placement Speed:
Surface Mounting
• CHIP 12,500 IPC9850
• IC 4,1000 CPH IPC9850
when using vision camera

JM-20 Insertion Speed:
Vacuum: 0.8 sec/part (x3)
Gripper: 1.3 sec/part (x3)

JM-10/20 Placement Accuracy:
Surface Mounting
• Laser Recognition: ±0.05mm(±3σ)
• Vision: ±0.04mm
